Excavator Main Pump 369-9655 576-3072 E374F 374FL Hydraulic Pump

1 Sets
MOQ
Negotiable
Price
Excavator Main Pump 369-9655 576-3072 E374F 374FL Hydraulic Pump
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: 374F E374F 374FL
Part Number: 369-9655 576-3072
Place Of Origin: Germeny
Weight: 280KG
Warranty: 6months
Delivery Time: 3days
Keyword: 374F Hydraulic Pump
Condition: Genuine Or OEM
Appliion: Excavator
Packaging Wooden: Wooden Box With Safty
Video Outgoing-inspection: Provided
Highlight:

369-9655

,

576-3072

Basic Infomation
Place of Origin: Germeny
Model Number: 374F 374FL 390F
Payment & Shipping Terms
Packaging Details: Wooden box
Delivery Time: 3 days
Payment Terms: L/C,T/T, Western Union, Tradeassurance
Supply Ability: 50-Sets/month
Product Description

Excavator main pump 374F E374F 374FL hydraulic pump 35770446 369-9655



Product Descriptio



Pos. Part No Qty Parts name
1 241-4007 [4] SCREW-LOCK
2 326-4428 [1] SEAL-SHAFT
3 165-9353 [1] BLOCK
4 458-6021 Y [1] CONTROL AS-PISTON PUMP (FRONT)
5 458-6022 Y [1] CONTROL AS-PISTON PUMP (REAR)
6 458-6023 Y [2] VALVE GP-PUMP CONTROL
7 514-1339 [1] LEVER AS-CONTROL (FRONT)
8 514-1340 [1] LEVER AS-CONTROL (REAR)
9 458-6026 [2] VALVE GP-SHUTTLE
10 458-6027 Y [1] HOUSING GP-PUMP (FRONT)
11 458-6028 Y [1] HOUSING GP-PUMP (REAR)
12 458-6029 Y [1] ROTATING GP-PUMP (FRONT)
13 458-6030 Y [1] ROTATING GP-PUMP (REAR)
14 458-6031 [2] SENSOR GP-POSITION
      (EACH INCLUDES)
  6V-8653 M [2] BOLT-SOCKET HEAD (M6X1X40-MM)
  448-1451 [1] SENSOR
  369-9618 [1] SENSOR GP-POSITION
  107-3117 [1] SEAL-O-RING
15 458-6032 [1] SHAFT-FRONT
16 458-6033 [1] SHAFT-REAR
17 436-4966 [1] RETAINER-RING
18 458-6035 [1] COUPLING
19 123-2017 [6] PLUG-BREAK OFF
20 464-7720 [1] PLUG
21 9T-3871 [2] SEAL-RECTANGULAR
22 464-9280 [4] PIN-CYLINDER
23 464-9278 [2] GASKET
24 464-9286 M [8] SCREW-STOP (M8X1.25X15-MM)
25 512-4657 [1] BLOCK
26 512-5286 [1] BLOCK
27 464-9279 [2] BEARING
28 512-5287 [2] PIN-CYLINDER

      AVAILABLE REPAIR KIT(S):
  458-6037 Y [1] KIT-SEAL (MAIN HYDRAULIC PUMP)
  458-6038 Y [2] KIT-SEAL (MAIN HYDRAULIC PUMP)(HEAD)
  458-6036 Y [2] KIT-BEARING (SHAFT)
  458-6965 Y [2] KIT-BEARING (SWASHPLATE)
  M   METRIC PART
  Y   SEPARATE ILLUSTRATION













Excavator Main Pump 369-9655 576-3072 E374F 374FL Hydraulic Pump 0Excavator Main Pump 369-9655 576-3072 E374F 374FL Hydraulic Pump 1



Maintenance method

1. When the excavator is working, when the excavator makes abnormal sounds from the pump, the excavator vibrates, or the computer board displays a fault code or alarm, be sure to stop the machine and check whether it is caused by a pump failure.



2. When the operating environment temperature of the excavator is very low, be sure to let the excavator idle for more than 10 minutes after starting. Wait for the excavator temperature to come up before adding load to the excavator to ensure normal operation of the excavator. The hydraulic pump is working properly.



3. When the excavator is operating normally, you must always pay attention to whether the temperature of the excavator's hydraulic oil is too high? Is the excavator water temperature too high?



About Xinfeng Machinery (XF) parts:



Xinfeng Machinery Parts Company was established in 1998. It is a professional team composed of high-quality technical personnel integrating production, maintenance, sales, and service. It is committed to providing customers with high-quality and efficient services. It is headquartered in Guangzhou, China.



We have been engaged in the excavator industry for 25 years. We sell original used parts, rebuilt parts,original new parts, and OEM new parts for many types.We can provide many types for you to choose from. We can provide a quality-trusted full range of hydraulic pumps, travel motors, final drives, main control valves, swing motors, and engines for KOMATSU, , HITACHI, JOHN DEERE, VOLVO, CASE JCB, KOBELCO, NEW HOLLAND, SUMITOMO, KATO, BOB, DOOSAN, and HYUNDAI.



We provide a customer satisfaction guarantee on all our products. We have invested in providing only the highest-quality replacement parts to our customers. Develop a more broad business space together based on long-term, friendly, mutually beneficial, and win-win business relations.





Excavator Main Pump 369-9655 576-3072 E374F 374FL Hydraulic Pump 2









If you encounter any technical problems with the excavator, you can consult us
