Product Descriptio
| Pos. | Part No | Qty | Parts name | Comments |
| . . | YN32W00019F1 | [1] | GEAR REDUCTION UNIT | SM Reduction Assy (Swing) Superseded by part number: YN32W00022F2 |
| 1 | YN32W01051P1 | [1] | SHAFT | SM |
| 2 | YN32W01052P1 | [1] | GEAR | SM Sun |
| 3 | YN32W01053P1 | [3] | GEAR | SM Pinion |
| 4 | YN32W01054P1 | [1] | GEAR | SM Sun |
| 5 | YN32W01055P1 | [4] | GEAR | SM Pinion |
| 6 | YN32W01056P1 | [1] | RING GEAR | SM |
| 7 | YN32W01057F1 | [1] | CARRIER | SM Spider Assy |
| 7-1. | YN32W01009P1 | [1] | ||
| 7-2. | YN32W01066P1 | [3] | SHAFT | KOB |
| 8 | YN32W01058P1 | [1] | CARRIER,Housing, Spider | SM Spider |
| 9 | YN32W01067P1 | [4] | SHAFT | SM |
| 10 | YN32W01030P1 | [1] | SPHERICAL BEARING | KOB Spherical Superseded by part number: 25Z804D18 |
| 11 | YN32W01029P1 | [1] | SPHERICAL BEARING | KOB Spherical Superseded by part number: R25P0047D9 |
| 12 | YN32W01060P1 | [1] | OIL SEAL | SM Oil Seal |
| 13 | YN32W01104P1 | [1] | BOX | SM Housing Superseded by part number: YN32W00022F2 |
| 15 | YN32W01071P1 | [6] | WASHER | SM Washer, Thrust |
| 16 | YN32W01073P1 | [3] | NEEDLE BEARING | SM Needle |
| 17 | YN32W01072P1 | [4] | NEEDLE BEARING | SM Needle |
| 18 | YN32W01063P1 | [8] | WASHER | SM Thrust |
| 19 | ZR16X03500 | [1] | RING | KOB Retaining |
| 20 | ZR16X09000 | [1] | RING | KOB Retaining |
| 21 | YN32W01082P1 | [1] | SLEEVE | SM |
| 22 | ZP26D08025 | [4] | PIN | KOB Spring |
| 23 | HS23C14135G1 | [11] | SCREW,M14 x 135mm | SM Cap |
| 24 | PV02B01073D8 | [2] | CAP | KOB |
| 25 | YN32W01080D1 | [1] | RIGID TUBE | SM |
| 26 | ZG31U08000 | [1] | HYD CONNECTOR | SM Elbow |
| 27 | ZE82T08000 | [1] | PLUG | KOB |
| 28 | ZR16X04000 | [3] | RING | KOB Retaining |
| 30 | YN32W01081P1 | [1] | OIL SEAL | SM Oil Seal |
| 31 | ZG91V02000 | [1] | LUBE NIPPLE,67 Degree x 1/8" PT | KOB 67° x 1/8" PT Superseded by part number: 72283072 |
| 32 | 2444Z3305 | [1] | BREATHER | KOB Valve, Relief |
